Active Drone Detector with Security Alarming Radar for Medium and Short Range UAV Detection for Surveillance & Protection
Póngase en contacto conmigo para muestras y cupones gratis.
¿Qué es?:0086 18588475571
El Wechat: 0086 18588475571
¿ Qué pasa?: sales10@aixton.com
Si tiene alguna preocupación, ofrecemos ayuda en línea las 24 horas.
xDatos del producto
| Aplicación | Protección contra la seguridad | Característica | durable |
|---|---|---|---|
| Tipo | Detector de la señal | Abejón | 1,2 kilómetros |
| Cobertura de acimut | 90 grados | Cobertura de elevación | 40 grados |
| Cobertura de acimut | 360 ° | Especificación | Banda C (5,5-5,8 GHz) |
| Resaltar | short range UAV detector,drone detection radar for surveillance,security alarming radar for drones |
||
Descripción de producto
Product Description
Air Surveillance Radar
LAS-1C1K / C band
LAS-1C1K, Adopting DBF technology, can directly control the amplitude and phase of each radiation unit through digital means, flexibly generating beams and beam pointing of various shapes.
Features
-- High data rate and high positioning accuracy
-- Multi-Input Multi-Output (MIMO) system
-- All-weather adaptability
Application
Airports, border areas and other key areas security surveillance
Specification
LAS-1C1K / C band
LAS-1C1K, Adopting DBF technology, can directly control the amplitude and phase of each radiation unit through digital means, flexibly generating beams and beam pointing of various shapes.
Features
-- High data rate and high positioning accuracy
-- Multi-Input Multi-Output (MIMO) system
-- All-weather adaptability
Application
Airports, border areas and other key areas security surveillance
Specification
| Item | Specification |
| Working mode | Phased array + Pulse Doppler |
| Working frequency | C band (5.5-5.8GHz) |
| Detection range | 1.2km (DJI Phantom 3/4," Mavic", RCS≈0.01 square meter) |
| Minimum detection range | ≤100m |
| Azimuth coverage | Single panel:90° ( Dual panel:180°, 3-panel:270°, 4-panel:360°) |
| Elevation coverage | 40° |
| Distance accuracy | ≤10m |
| Azimuth Accuracy | ≤1.0° |
| Target detection speed | 0.2m/s - 25m/s |
| Speed precision | ≤0.2m/s |
| Data rate | ≤1.5s |
| Peak Output | 4W/Panel |
| Net weight | ≤10kg |
| Power supply | AC220V/40W |
| Interface | Ethernet (UDP protocol) |
| Dimension | 445mm X 300mm X 400mm |
| Working temperature | -40 ºC ~ +60 ºC |
| Working Environment | Rain-proof; Dust Prevention; Sand-prevention; Moisture-proof, Mould-proof and Salt-proof |
ABOUT US
Certification
Why Choose Us?
OEM/ODM capabilities
Competitive pricing & bulk discounts
Fast shipping & customs clearance support
Turnkey project solutions
FAQ
Q: What’s the lead time for orders?
A: Standard models ship in 15–30 days; customized units require 30–45 days.
Q: Do you provide after-sales service overseas?
A: Yes, we have partnered service centers in key regions.
Q: Can I request a customized bucket size?
A: Absolutely! We offer tailored attachments.
Q: What documents do you provide for export?
A: Full export package (Commercial Invoice, Packing List, Bill of Lading, COC, etc.).
Q: How do I place an order?
A: Contact us via email/phone for a quote, then confirm with a PO.
