100W GaN Lora 700-1020Mhz Digital Signal RF Module Broadband Wide Anti-Drone FPV UAV Amplifier for Defense System

  • 100W GaN Lora 700-1020Mhz Digital Signal RF Module Broadband Wide Anti-Drone FPV UAV Amplifier for Defense System
  • 100W GaN Lora 700-1020Mhz Digital Signal RF Module Broadband Wide Anti-Drone FPV UAV Amplifier for Defense System
  • 100W GaN Lora 700-1020Mhz Digital Signal RF Module Broadband Wide Anti-Drone FPV UAV Amplifier for Defense System
  • 100W GaN Lora 700-1020Mhz Digital Signal RF Module Broadband Wide Anti-Drone FPV UAV Amplifier for Defense System
  • 100W GaN Lora 700-1020Mhz Digital Signal RF Module Broadband Wide Anti-Drone FPV UAV Amplifier for Defense System
  • 100W GaN Lora 700-1020Mhz Digital Signal RF Module Broadband Wide Anti-Drone FPV UAV Amplifier for Defense System
Lugar de origen Shaanxi, China
Nombre de la marca UND
Número de modelo UND-AM50
Cantidad de orden mínima 10
Precio $155-165

Póngase en contacto conmigo para muestras y cupones gratis.

¿Qué es?:0086 18588475571

El Wechat: 0086 18588475571

¿ Qué pasa?: sales10@aixton.com

Si tiene alguna preocupación, ofrecemos ayuda en línea las 24 horas.

x
Datos del producto
Tipo Módulo de RF Potencia de salida 50W
Frecuencia 720-1020MHz Dimensión 117*40*18mm
Peso 230G
Resaltar

100W GaN RF amplifier module

,

Anti-drone signal amplifier 700-1020Mhz

,

FPV UAV broadband defense system module
Deja un mensaje
Descripción de producto
 100W GaN Lora 700-1020Mhz Digital Signal RF Module Broadband Wide Anti-Drone FPV UAV Amplifier for Defense System 0

Test items

Index

Unit

Remark

Frequency range

700-1000

Mhz

With signal source

Operating voltage

24-32

V

Typical voltage 28V built-in voltage regulator module

Maximum output power

50

dBm

≤7.3A

Power supply requirements

≥10

A



Work efficiency

50

%

Typical work efficiency

Output port VSWR

≤2





High and low temperatur e test

Working environment temperature
(℃)

-40~+55

℃



Power stability

1.5

dB

-20℃~+75℃

Power supply

M4 Feedthrough
Capacitor



Red and black wire or
through-hole capacitor

Communication interface

CON2*4



1,2,3,4 pin NC
8pin enable (hight open, low close)
6pin         temperature alarm (normal  high level, alarm low level) 7pin standing wave alarm (normal  high
level, alarm low level)
5pinGND

RFoutput connector

N



Female

Size

156.5*64.7*24.5

mm

Not including connector

Mounting holes

151.5*59.4



M3*10 steel screw


 100W GaN Lora 700-1020Mhz Digital Signal RF Module Broadband Wide Anti-Drone FPV UAV Amplifier for Defense System 2100W GaN Lora 700-1020Mhz Digital Signal RF Module Broadband Wide Anti-Drone FPV UAV Amplifier for Defense System 4100W GaN Lora 700-1020Mhz Digital Signal RF Module Broadband Wide Anti-Drone FPV UAV Amplifier for Defense System 6100W GaN Lora 700-1020Mhz Digital Signal RF Module Broadband Wide Anti-Drone FPV UAV Amplifier for Defense System 8
